dsg-03-3c2-d24-n1-50 solenoid directional valve YUKEN

The DSG-03-3C2-D24-N1-50 solenoid directional control valve is a compact, three-position, four-way solenoid directional control valve from the YUKEN brand. It features efficient switching, fast response, and stable performance, making it widely used in engineering machinery, metallurgical equipment, petrochemicals, and other fields.
I. Product Overview
The DSG-03-3C2-D24-N1-50 solenoid directional control valve belongs to the YUKEN DSG series, which is renowned for its compact design, efficient switching capability, and stable performance. This valve utilizes electromagnetic actuation, controlling the movement of the valve core through electromagnetic force to achieve fluid flow diversion, offering fast response and high control accuracy.
II. Model Meaning
DSG: Series designation for the solenoid directional control valve.
03: Flow rating code for a set pressure of 31.5 MPa; 03 indicates a flow rate of 16 L/min.
3C2: Interface type code for the directional control valve; 3C2 indicates a hydraulic port connection. D24: The operating voltage code for the directional valve’s solenoid. D24 indicates DC 24V.
N1: The code for the directional valve’s open-center position. N1 indicates closed-center position.
50: The serial number of the directional valve. The serial number uniquely identifies the product and varies depending on the model.

III. Product Features
Compact Structure: The compact design facilitates installation in limited spaces and is suitable for a variety of hydraulic systems and equipment.
Three-position, four-way directional control: The DSG-03 series valves typically feature a three-position, four-way structure with three operating positions and four oil ports, meeting complex hydraulic control requirements.
Solenoid Drive: Electromagnetic force controls the movement of the valve core, achieving fluid switching, with fast response and high control accuracy.
Material and Seal: Made of high-quality materials, it offers excellent corrosion resistance and sealing properties, ensuring long-term stable operation.
Voltage and Interface: Powered by 24V DC, the DSG-03 series valves feature a well-configured interface for easy connection to other hydraulic components.

IV. Application Areas
The DSG-03-3C2-D24-N1-50 solenoid directional control valve is widely used in various industrial fields, including but not limited to:
Construction Machinery: Controls the hydraulic systems of equipment such as excavators, loaders, and road rollers.
Metallurgical Equipment: Controls hydraulic transmission systems in smelting and rolling processes in the steel and nonferrous metal industries.
Petrochemical Industry: Controls the flow direction and pressure of fluids within pipelines in the oil refining and chemical industries.
Marine and Offshore Engineering: Provides reliable hydraulic control solutions for critical components such as ship propulsion systems and mooring systems.
