A10VSO series Rexroth Piston Pump
Whats app: +86 13728707767
E-mail: hyd-sales2009@outlook.com
We are a professional manufacturer of hydraulic pumps, offering a complete range of products. Inquiries are welcome! (#^.^#)
Rexroth A10VSO Series Axial Piston Variable Pump: Specifications and Applications
1. Product Overview
2. Core Specifications
2.1 Series Classification & Displacement Range
-
Series 31: All-purpose medium-pressure pumps with displacement sizes from 18 cm³ to 140 cm³ (e.g., A10VSO 18, 45, 71, 100, 140). Typical models include A10VSO 71 DG/31R, A10VSO 140 DFLR/31R.
-
Series 32: Industrial-grade pumps optimized for heavy-duty applications, with displacement sizes ranging from 45 cm³ to 180 cm³ (e.g., A10VSO 71 DR/32R, A10VSO 180 DRF/32R).
2.2 Key Performance Parameters
|
Parameter
|
Value Range
|
Notes
|
|---|---|---|
|
Nominal Working Pressure
|
280 bar (4000 psi)
|
Standard for all sub-series
|
|
Maximum Peak Pressure
|
350 bar (5100 psi)
|
For short-term overload conditions
|
|
Drive Speed
|
Up to 1500 rpm (typical)
|
Varies by size; high-speed versions (140/180 cm³) feature double retainer mechanisms
|
|
Maximum Flow Rate
|
Up to 270 l/min
|
Calculated at maximum displacement and rated speed (A10VSO 180 model)
|
|
Operating Temperature
|
-20°C to 90°C
|
Leakage oil temperature must not exceed 90°C
|
|
Weight
|
37 kg to 85 kg
|
Depends on displacement size and control configuration
|
2.3 Structural & Installation Specifications
-
Sealing Material: FKM (Viton) as standard, ensuring compatibility with most hydraulic fluids.
-
Mounting Configuration: ISO 3019-2 (metric) mounting flange with 2-hole design; supports below-reservoir, inside-reservoir, and above-reservoir installation.
-
Shaft End: ISO standard shaft key for reliable power transmission; optional through-drive for combination pump setups (A10VSO + A10VSO).
-
Port Design: Two drain ports; pump outlet equipped with a port for pressure transducers; B/S flanged metric working ports.
2.4 Control Methods
-
Pressure Control (DR): Direct pressure regulation with adjustable setpoints (20-250 bar via setting screw).
-
Pressure-Flow Control (DRF/DRS): DRF for open-loop X-T control, DRS for closed-loop X-T control, integrating both pressure and flow regulation.
-
Remote Pressure Control (DRG): Hydraulically controlled remote pressure adjustment for flexible system integration.
-
Electronic Displacement Control (DFE): Electrically proportional displacement control with pressure feedback, enabling automated system adjustment.
-
Power Control (LA5D/LA6D/LA7D): Combines pressure control with power limiting, with adjustable control start points (50-160 bar).
3. Applications
3.1 Industrial Machinery
-
Machine Tools: Used in CNC machining centers, lathes, and milling machines for precise feed drive and spindle control, benefiting from low noise and stable flow output.
-
Plastic Processing: Applied in injection molding machines and extruders to drive clamping units and screw mechanisms, with pressure-flow control ensuring consistent molding quality.
-
Metallurgy & Forging: Suitable for hydraulic presses, rolling mills, and smelting equipment, enduring high-pressure and heavy-load conditions with long service life.
3.2 Construction & Mining Machinery
-
Mining Equipment: Integrated into excavators, loaders, and drill rigs, providing powerful hydraulic drive for digging, lifting, and drilling operations.
-
Crane Systems: Used in mobile and stationary cranes to control hoisting, luffing, and slewing mechanisms, with precise pressure control ensuring operational safety.
3.3 Other Fields
-
Agricultural Machinery: Adapted for large-scale farm equipment such as combine harvesters and tractors, handling variable loads and harsh outdoor environments.
-
Marine & Offshore: Applied in ship deck machinery (winches, cranes) and offshore drilling platforms, with corrosion-resistant options available for marine conditions.
-
Energy & Utilities: Used in hydroelectric power plants and wind turbine pitch control systems, delivering reliable performance in continuous operation scenarios.
4. Key Advantages
-
Optimized housing and port plate structure minimize noise radiation, meeting industrial noise standards.
-
Hydrostatic unloading of cradle bearings reduces wear and extends service life.
-
Built-in pressure cut-off valve and dual relief valves on the high-pressure side provide overload protection.
-
Excellent power-to-weight ratio and compact design enable easy integration into limited installation spaces.
-
Compatible with hydraulic fluids meeting NAS 1638 Class 9 cleanliness requirements, ensuring system reliability.
Complete products, original authentic products, fast delivery!Welcome to consult.
