Parker PGP517 series gear pump specifications

The specifications of Parker PGP517 series gear pumps are as follows：
Working pressure：
The maximum operating pressure can reach 240 bar (3481 psi), and the continuous operating pressure can reach 275 bar under some operating conditions.
Speed range：
The maximum speed can reach 3300 rpm, and the specific speed range may vary depending on the model.
Displacement selection：
The maximum displacement can reach 50.3 cm3/rev (3.07 in3/rev), and the displacement ranges from a smaller value to 50.3 cm3/rev, depending on the model.
Temperature range：
The highest fluid temperature can reach 70°C (158°F) and the lowest fluid temperature can reach -40°C (-40°F).
Material and structure：
The material of the pump body may include copper alloy, cast iron, etc., depending on the model and application requirements.
It is made of high-strength materials, the bearing load is relatively reduced, and it can be adapted to work under high pressure conditions.
Some models adopt roller bearing structure, which gives the gear pump high durability and oil pollution resistance.
Noise level：
The highest noise level is 63 dBA @2950 RPM, and noise damping technology is used to provide a quiet working environment.
Installation and connection：
A variety of sizes and configuration options are available to meet the needs of different applications.
It has various installation flanges, shaft extensions, oil inlet and oil outlet connection forms that meet SAE and international standards GB.
It can be composed of a double pump and a multi-pump, and the multi-pump can reach up to 4.
Application flexibility：
The installation and connection dimensions are internationalized, and various valve groups and multi-pump configurations with common imports can be integrated.
It provides unparalleled flexibility in design and application, and is suitable for a variety of industrial pump application scenarios.
