A10 series Yuken Variable piston pump
Youyan A series variable piston pumps have a wide range of displacement, ranging from 10cm3/rev to 219cm3/Rev. Common displacement includes: A10, A16, A22, A37, A56, A70, A90, A145
E-mail: hyd-sales2009@outlook.com
YUKEN Variable Displacement Piston Pump Series A10 – Models and Related Parameters
1. Model Nomenclature of Series A10
-
A10: Series designation, indicating the variable displacement piston pump of Series A10.
-
F: Mounting type, flange mounting (standard type for Series A10; foot mounting requires an additional mounting bracket).
-
R: Rotation direction, clockwise when viewed from the shaft end (standard type; counterclockwise rotation is available on request except for A100 model).
-
01: Control method, pressure compensator control type.
-
B/C/H: Pressure adjustment range (B: 1.2~7 MPa; C: 2.0~16 MPa; H: 2.0~21 MPa).
-
12: Design number, standard design for Series A10.
2. Main Models and Key Technical Parameters
|
Model
|
Geometric Displacement (cm³/rev)
|
Rated Pressure (MPa / psi)
|
Maximum Intermittent Pressure (MPa / psi)
|
Shaft Speed Range (r/min)
|
Minimum Adjustable Flow (cm³/rev)
|
Approx. Mass (kg / lbs)
|
Pressure Adjustment Range (MPa)
|
|---|---|---|---|---|---|---|---|
|
A10-FR01B-12
|
10.0
|
16 / 2320
|
21 / 3050
|
600 ~ 1800
|
2.0
|
8.5 / 18.7
|
1.2 ~ 7
|
|
A10-FR01C-12
|
10.0
|
16 / 2320
|
21 / 3050
|
600 ~ 1800
|
2.0
|
8.5 / 18.7
|
2.0 ~ 16
|
|
A10-FR01H-12
|
10.0
|
16 / 2320
|
21 / 3050
|
600 ~ 1800
|
2.0
|
8.5 / 18.7
|
2.0 ~ 21
|
3. Additional Technical Specifications
-
Control Method: Pressure compensator control (standard); other control methods are available on request.
-
Hydraulic Fluid: Petroleum-based oil (ISO VG32 recommended); the operating temperature range is 0 ~ 60 °C.
-
Mounting Note: Series A10 adopts flange mounting as standard. If foot mounting is required, an additional mounting bracket (Part No. LP-1A-10) must be ordered separately, with a bracket mass of 2.2 kg.
-
Response Time: Under the condition of 1500 r/min shaft speed, ISO VG32 oil, and 50 °C oil temperature, the response time is approximately 2.6 ms.
-
Pressure Adjustment: Turning the pressure adjustment screw clockwise increases the pressure; each full turn of the screw adjusts the pressure by 2.9 MPa for A10-FR01B, and 5.4 MPa for A10-FR01C/H.
4. Important Notes
Complete products, original authentic products, fast delivery!Welcome to consult.
