REXROTH A4VG Series Variable Displacement Piston Pump – Specifications & Model Explanation
1. Model Explanation
-
The series is mainly used in closed-loop hydrostatic transmission systems, with optional control modes to match different load requirements.
-
Models compatible with high-temperature and high-dust working conditions adopt corrosion-resistant seals and cast iron housings to enhance durability.
-
Optional integrated accessories include overflow valves, balance valves, and flushing valves, which need to be specified in the configuration code during selection.
-
Interface specifications support SAE flanges and threaded ports; the specific type is indicated by the middle section of the model.
-
A4VG: Series identifier (closed-loop variable displacement piston pump)
-
56: Rated displacement (56 cm³/r)
-
DA2D2: Control mode (double-acting proportional control with pressure compensation)
-
32R: Interface specification (32 series flange, right-hand rotation)
-
NZF02F021S: Configuration code (integrated safety valve, standard installation)
2. Core Specifications
2.1 Displacement Range
-
Standard Models: 40 cm³/r to 180 cm³/r (rated displacement at maximum swashplate angle)
-
Stepless Adjustment: Displacement is continuously adjustable via swashplate angle, adapting to variable flow demand.
2.2 Operating Pressure
-
Nominal Pressure: 32 MPa (4641 PSI)
-
Peak Pressure: 40 MPa (5802 PSI) (short-term operation, ≤5 minutes)
2.3 Speed Range
-
Rated Speed: 1500 – 2500 rpm
-
Minimum Stable Speed: ≥100 rpm (no cavitation)
-
Maximum Allowable Speed: 3000 rpm (continuous operation)
2.4 Other Key Parameters
-
Noise Level: ≤70 dB (at rated speed and pressure)
-
Working Temperature: -20℃ to 90℃ (hydraulic oil temperature)
-
Hydraulic Oil Compatibility: Mineral oil, synthetic hydraulic oil (meets DIN 51524 standard)
-
Drive Shaft Load Capacity: Radial load ≤ 2500 N; Axial load ≤ 1000 N
3. Product Features
-
Closed-Loop Design: Optimized for hydrostatic transmission systems, minimizing oil leakage and improving energy efficiency compared to open-loop pumps.
-
Multiple Control Modes: Supports pressure compensation control (DR), power control (LR), and electric proportional control (EO2), meeting diverse system control requirements.
-
Robust Construction: Cast iron housing and high-precision swashplate ensure stable operation in harsh conditions such as high pressure, high dust, and vibration.
-
Integrated Accessories: Optional built-in valves reduce pipeline complexity and installation space, enhancing system reliability.
-
Global Compliance: Meets ATEX, CE certifications, suitable for industrial and mobile equipment in global markets.
-
Wide Application: Ideal for construction machinery, mining equipment, port cranes, and metallurgical machinery hydraulic systems.
