CBG3 Series gear pumps
Whats app: +86 13728707767
E-mail: hyd-sales2009@outlook.com
We are a professional manufacturer of hydraulic pumps, offering a complete range of products. Inquiries are welcome! (#^.^#)
Description
Overview
The CBG3 gear pump is a high-performance medium and high-pressure hydraulic component, serving as a core power element in hydraulic systems. Characterized by its simple structure, reliable operation, excellent impact resistance, and easy maintenance, this series is widely applied in hydraulic devices of construction machinery, marine machinery, hoisting machinery, mining machinery, and environmental sanitation equipment. It can be configured as a single pump or a duplex pump to meet diverse system requirements.
Core Features
-
Sturdy Construction: The pump housing adopts liquid extrusion molding technology and high-strength ductile iron, ensuring strong load-bearing capacity. The gears are made of high-strength alloy steel, paired with high-performance roller bearings, which significantly enhance overload resistance, pollution resistance, and service life.
-
High Efficiency & Stability: Equipped with an automatic axial clearance compensation mechanism, the pump maintains high volumetric efficiency (≥92%) and total efficiency (≥83%) during long-term operation. The optimized involute tooth profile design (module customized, pressure angle 30°) ensures stable flow output, small pressure pulsation, and strong self-priming capacity.
-
Low Noise & Durability: Precision machining and optimized structural design effectively reduce wear and operating noise, making it suitable for harsh working conditions. It operates stably in a wide temperature range of -20℃ to 80℃, with recommended working oil temperature between 40℃ and 65℃.
-
Flexible Configuration: Multiple shaft extension types are available, including plain key, rectangle spline, involute spline, etc. The mounting form and oil port connection adopt standard flange designs for easy installation and replacement.
Model Coding Explanation
Example: CBG3100-B-F-H-R
-
Product Code: CBG – Standard gear pump product identifier.
-
Nominal Displacement: 3100 – The first digit “3” represents the series, and the following digits “100” indicate nominal displacement of 100 ml/r.
-
Mounting Form: B – Square flange mounting (standard configuration).
-
Oil Port Form: F – Flange connection for oil ports.
-
Shaft End Form: H – Rectangle spline; P – Plain key (other types available on request).
-
Rotation Direction: R – Left rotation (counterclockwise); Right rotation (clockwise) is omitted as the default.
Key Performance Specifications
|
Model
|
Nominal Displacement (ml/r)
|
Rated Pressure (MPa)
|
Max Pressure (MPa)
|
Rated Speed (r/min)
|
Max Speed (r/min)
|
Rated Power (kW)
|
Weight (kg)
|
|---|---|---|---|---|---|---|---|
|
CBG3100
|
100
|
16
|
20
|
2000
|
2400
|
58.1
|
42
|
|
CBG3125
|
125
|
12.5
|
16
|
2000
|
2400
|
72.6
|
43.5
|
|
CBG3140
|
140
|
12.5
|
16
|
2000
|
2400
|
81.5
|
44.5
|
|
CBG3160
|
160
|
12.5
|
16
|
2000
|
2400
|
90.0
|
45.5
|
|
CBG3200
|
200
|
12.5
|
16
|
2000
|
2400
|
90.8
|
48.5
|
Note: Working oil viscosity should be 20~40 m㎡/s, and filtration precision shall not be lower than 25 microns. Suitable for hydraulic oil (YA-N68/GB2512-81) or equivalent lubricants.
Application Fields
The CBG3 series gear pump is widely used in hydraulic systems of loaders, excavators, rollers, forklifts, cranes, bulldozers, environmental sanitation vehicles, mining equipment, and marine auxiliary machinery. It provides stable hydraulic power support for various heavy-duty equipment, ensuring efficient and reliable operation in complex working environments.
