F11-025 series Parker hydraulic motor
F11-005、 F11-006、 F11-010、 F11-012、 F11-014、 F11-019、 F11-150、 F11-250、 F12-30、 F12-40、 F12-60、 F12-80、 F12-90、 F12-110、 F12-125、 F12-152、 F12-162、 F12-182、 F12-250
E-mail: hyd-sales2009@outlook.com
Specifications of Parker Hydraulic Motor F11-025 Series
|
Specification Item
|
Parameter Value
|
Remarks
|
|
Model
|
F11-025 Series
|
Fixed displacement, bent-axis type
|
|
Displacement
|
25 cm³/rev (25 ml/r)
|
Nominal displacement
|
|
Operating Pressure
|
Peak: 420 bar (6090 psi); Continuous: 350 bar (5076 psi)
|
Intermittent pressure: max 6 seconds in any one minute
|
|
Operating Speed
|
Max Intermittent: 3000 rpm; Max Continuous: 2600 rpm; Min Continuous: 50 rpm
|
–
|
|
Self-priming Speed
|
1700 rpm
|
Valid at sea level
|
|
Torque
|
40 Nm (at 10 MPa)
|
Calculated based on basic hydraulic motor formula
|
|
Flow Rate
|
Max Intermittent: 75 L/min; Max Continuous: 65 L/min
|
Calculated by displacement and speed
|
|
Operating Temperature Range
|
Min: -40 °C; Max: 80 °C
|
Main circuit temperature limit
|
|
Rotation Direction
|
Left (L) or Right (R) operation
|
Selectable according to application needs
|
|
Weight
|
19 kg
|
Approximate weight without additional accessories
|
|
Mounting Flange
|
CETOP and SAE versions available
|
SAE ‘D’ (SAE J 744 C) mounting flange for SAE version
|
|
Screw Tightening Torque
|
80 ± 15 Nm
|
Applicable to F11-025 series
|
|
Shaft Type
|
Spline shaft (DIN 5480) available
|
Specific dimensions refer to installation drawings
|
Key Features
-
Bent-axis design with 40° angle between shaft and cylinder barrel, ensuring compact structure and light weight, suitable for small installation spaces.
-
High intermittent and continuous operating pressure, enabling stable output power in small to medium-sized equipment.
-
Laminated piston ring design reduces internal leakage and improves thermal shock resistance, ensuring long-term reliable operation.
-
Reliable structure with timing gear and bearing setup, ensuring long service life and strong vibration resistance in harsh working environments.
| F11-005-GB-CV-K-000-0000 F11-005-HB-CV-K-000-000 F11-005-MB-CV-K-000-0000 F11-005-RB-CV-D-000-0000 F11-006-MB-CV-K-000-0000 F11-006-MB-IV-K-000-000 F11-010-HU-CV-K-000-0000 F11-010-MB-CV-K-000-0000 F11-010-RB-CV-K-000-0000 F11-012-QU-CV-K-000-000 F11-012-RB-CV-K-000-0000 F11-014-HB-CV-K-000-000 F11-014-LU-SV-S-000-0000 F11-014-SF-IV-K-000-0000 F11-019-HB-CV-D-000-0000 |
F11-019-MB-CN-K-000-0000 F11-019-MB-CV-K-000-0000 F11-019-RB-CV-K-000-0000 F12-030-LF-IV-K-000-000 F12-030-LF-IV-P-000-000 F12-030-LS-SV-S-000-000 F12-030-LS-SV-T-000-000 F12-030-LS-TV-P-000-000 F12-030-LS-TV-S-000-000 F12-030-LS-TV-T-000-000 F12-030-MF-IV-P-000-000 F12-030-RS-SV-S-000-000 F12-030-RS-TV-S-000-000 F12-030-RS-TV-T-000-000 F12-030-SF-IS-P-000-000 |
F12-040-MF-IV-D-000-0000 F12-040-MF-IV-K-000-000 F12-040-MF-IV-K-000-0000 F12-040-MS-SN-T-000-000 F12-040-MS-SV-S-000-0000 F12-040-MS-SV-T-000-000 F12-040-MS-SV-T-000-0000 F12-040-MS-TV-T-000-000 F12-040-RF-IV-K-000-0000 F12-060-MF-IV-D-000-0000 F12-060-MF-IV-K-000-0000 F12-060-MS-SV-S-000-0000 F12-060-MS-SV-T-000-0000 F12-060-RF-IV-K-000-0000 F12-060-RS-SV-T-000-0000 |
F12-080-LF-IV-K-000-0000 F12-080-MF-IV-D-000-0000 F12-080-MF-IV-K-000-0000 F12-080-MS-SV-T-000-0000 F12-080-RF-IV-K-000-0000 F12-080-RS-SV-T-000-0000 F12-090-MF-IV-D-000-0000 F12-090-MS-SV-S-000-0000 F12-110-MF-IV-K-000-0000 F12-110-MS-SV-S-000-0000 F12-110-RF-IV-K-000-0000 F12-110-RS-SV-T-000-0000 F12-125-RF-IV-K-000-0000 F12-152-MF-FV-G-000-0000 F12-152-MF-SV-S-000-0000 |
Complete products, original authentic products, fast delivery!Welcome to consult.
