HSDW Series directional control valves
HSD Series directional control valve: HSDCV60EM 、HSDW 、HSDSL 、HSDCV55
E-mail: hyd-sales2009@outlook.com
HSDW Series Directional Control Valve Specifications
|
Parameter Category
|
Specifications
|
|
Nominal Flow
|
30-50 L/min (suitable for medium-flow hydraulic systems)
|
|
Rated Pressure
|
16-22 MPa; High-pressure model can reach 28 MPa (equivalent to 280 bar)
|
|
Maximum Pressure
|
Up to 320 bar (4641 psi)
|
|
Control Method
|
Manual, hydraulic, electro-hydraulic proportional control; Optional pneumatic control or solenoid control (12V/24V DC); 4/5-way commutation options available
|
|
Structure Type
|
Compact modular design, integral type or sectional type (cast flow channel for low pressure loss); Section number: 1-10 sections optional
|
|
Sealing Performance
|
Low-leakage design; Optional metal-to-metal sealing for high-temperature working conditions; “O” ring sealing for sectional type to ensure long-term tightness
|
|
Operating Viscosity Range
|
10-80 mm²/s (10 cst to 80 cst)
|
|
Operating Temperature Range
|
-30 °C to 90 °C (-22 °F to 194 °F)
|
|
Working Medium
|
Hydraulic oil, anti-wear hydraulic oil (ISO VG 32/46/68)
|
|
Connection Mode
|
Internal thread, flange connection optional; G thread, BSPP thread or SAE interface (subject to actual model)
|
|
Reliability
|
99.8% reliability; Built-in overload protection valve to enhance system safety; Smooth spool movement, long service life (≥10,000 hours)
|
|
Certifications
|
CE, ISO 9001, GB/T 13852-2018
|
Key Features
-
Compact modular structure: Small volume, easy to install and maintain, can be integrated with pressure control valves and flow control valves, reducing pipeline connections and potential leakage risks, and adapting to limited installation space.
-
Precise commutation control: Stable movement, fast response speed, accurate control of hydraulic oil flow direction, which can meet the precise control requirements of executive components and reduce system energy consumption.
-
Strong environmental adaptability: Wide operating temperature and viscosity range, optional metal hard sealing design, suitable for complex working conditions such as high temperature, high pressure and harsh medium, and widely used in engineering machinery, petrochemical and water treatment fields.
