Vickers PVM Series Variable Displacement Axial Piston Pumps – Specifications
1. Core Specifications
|
Model
|
Maximum Displacement
|
Continuous Pressure
|
Peak Pressure
|
Rated Speed
|
Output Flow @ Rated Speed
|
Noise Level (dBA)
|
Basic Weight
|
|---|---|---|---|---|---|---|---|
|
PVM018
|
18.0 cm³/r (1.1 in³/rev)
|
315 bar (4568 psi)
|
350 bar (5000 psi)
|
1800 rpm
|
31 lpm (8.2 gpm)
|
64 (max) / 56 (min)
|
15 kg (33 lbs)
|
|
PVM020
|
21.1 cm³/r (1.29 in³/rev)
|
230 bar (3300 psi)
|
280 bar (4000 psi)
|
1800 rpm
|
35 lpm (9.0 gpm)
|
64 (max) / 56 (min)
|
15 kg (33 lbs)
|
|
PVM045
|
46.1 cm³/r (2.75 in³/rev)
|
280 bar (4000 psi)
|
350 bar (5000 psi)
|
1800 rpm
|
76 lpm (20.0 gpm)
|
70 (max) / 66 (min)
|
24 kg (52 lbs)
|
|
PVM050
|
50.0 cm³/r (3.05 in³/rev)
|
230 bar (3335 psi)
|
280 bar (4000 psi)
|
1800 rpm
|
102 lpm (27.0 gpm)
|
70 (max) / 66 (min)
|
36 kg (79 lbs)
|
|
PVM057
|
57.4 cm³/r (3.50 in³/rev)
|
280 bar (4000 psi)
|
350 bar (5000 psi)
|
1800 rpm
|
102 lpm (27.0 gpm)
|
72 (max) / 67 (min)
|
36 kg (79 lbs)
|
|
PVM063
|
63.1 cm³/r (3.85 in³/rev)
|
230 bar (3335 psi)
|
280 bar (4000 psi)
|
1800 rpm
|
102 lpm (27.0 gpm)
|
72 (max) / 67 (min)
|
36 kg (79 lbs)
|
|
PVM074
|
73.7 cm³/r (4.50 in³/rev)
|
280 bar (4000 psi)
|
350 bar (5000 psi)
|
1800 rpm
|
127 lpm (33.5 gpm)
|
74 (max) / 71 (min)
|
45 kg (99 lbs)
|
|
PVM081
|
81.0 cm³/r (4.94 in³/rev)
|
230 bar (3335 psi)
|
280 bar (4000 psi)
|
1800 rpm
|
139 lpm (37.0 gpm)
|
74 (max) / 68 (min)
|
45 kg (99 lbs)
|
|
PVM098
|
98.3 cm³/r (6.00 in³/rev)
|
280 bar (4000 psi)
|
350 bar (5000 psi)
|
1800 rpm
|
170 lpm (45.0 gpm)
|
75 (max) / 68 (min)
|
55 kg (121 lbs)
|
|
PVM106
|
106.5 cm³/r (6.50 in³/rev)
|
230 bar (3335 psi)
|
280 bar (4000 psi)
|
1800 rpm
|
187 lpm (49.0 gpm)
|
78 (max) / 75 (min)
|
55 kg (121 lbs)
|
|
PVM131
|
131.1 cm³/r (8.00 in³/rev)
|
280 bar (4000 psi)
|
350 bar (5000 psi)
|
1800 rpm
|
215 lpm (57.0 gpm)
|
79 (max) / 74 (min)
|
66 kg (145 lbs)
|
|
PVM141
|
141.0 cm³/r (8.60 in³/rev)
|
230 bar (3335 psi)
|
280 bar (4000 psi)
|
1800 rpm
|
215 lpm (57.0 gpm)
|
79 (max) / 74 (min)
|
66 kg (145 lbs)
|
2. Model Code Interpretation
-
Product Series: PVM – M Series variable displacement axial piston pump
-
Displacement: 018 (18.0 cm³/r), 020 (21.1 cm³/r), 045 (46.1 cm³/r), etc.
-
Rotation Direction: R – Clockwise (Right-hand rotation); L – Counterclockwise (Left-hand rotation)
-
Control Mode: 0 – None; A – Pressure compensation; B – Pressure and flow compensation with drain orifice; C – Pressure and flow compensation without drain orifice
-
Mounting Flange: A – SAE J744-82-2 (A 2-bolt); C – SAE J744-101-2 (B 2-bolt)
-
Port Position: E – Rear port; S – Side port
-
Pressure Compensator Setting: 000 – None; 315 – 315±4 bar (adjustable range 140-315 bar); 230 – 230±4 bar (adjustable range 140-230 bar for 20cc models)
3. Key Features & Applications
3.1 Features
-
Open-loop axial piston swashplate design, compact structure with single-sided variable piston configuration.
-
Droplet-shaped housing reduces noise, providing operator comfort (noise level 56-79 dBA).
-
High overall efficiency reduces cooling system requirements and operating costs.
-
Durable bearing system and rigid drive shaft extend service life with low maintenance costs.
-
Standard adjustable maximum displacement regulator and pressure test ports for flexible system configuration.
-
Compatible with various hydraulic fluids, including petroleum-based, synthetic, high-water-based, and phosphate ester fluids.
