Vickers Vane Pumps and Double Vane Pumps – Specifications & Models
1. Overview
2. Single Vane Pumps
2.1 V10/V20 Series
2.1.1 Model Nomenclature
-
F3: Viton seals (omitted if not required)
-
Series Designation: V10 (small flow) / V20 (medium flow)
-
Installation: L = 2-bolt flange
-
Inlet Connection: P/S/M (V10: 1” NPT / 1.3125-12 UNF-2B / M33×2-7H; V20: 1.25” NPT / 1.625-12 UNF-2B / M42×2-7H)
-
Flow Code: Corresponding to flow rate at 1200 rpm and 6.9 bar (see Table 1)
-
Outlet Connection: P/S/R/M (V10: 1/2” NPT / 0.75-16 UNF-2B / M20×1.5-7H; V20: 3/4” NPT / 1.0625-12 UNF-2B / M27×2-7H)
-
Shaft Type: 1 = straight key; 11 = spline
-
Outlet Position: A = opposite inlet; B = 90° CCW from inlet; C = same side as inlet; D = 90° CW from inlet (viewed from cover end)
-
Rotation: Clockwise (omitted); Counterclockwise (marked)
2.1.2 Technical Specifications
|
Series
|
Flow Code
|
Flow Rate (USGPM) @1200 rpm
|
Geometric Displacement (ml/r)
|
Max Speed (rpm)
|
Max Pressure (MPa)
|
Weight (kg)
|
|---|---|---|---|---|---|---|
|
V10
|
1
|
3.3
|
20
|
1800
|
14
|
≈8.5
|
|
2
|
6.6
|
40
|
||||
|
3
|
9.8
|
60
|
||||
|
4
|
13.0
|
79
|
||||
|
5
|
16.5
|
101
|
||||
|
6
|
19.5
|
119
|
||||
|
7
|
23.0
|
140
|
||||
|
V20
|
6
|
19.5
|
119
|
1800
|
14
|
≈11.8
|
|
7
|
23.0
|
140
|
||||
|
8
|
26.5
|
162
|
||||
|
9
|
29.7
|
181
|
||||
|
10
|
33.0
|
200
|
||||
|
11
|
36.4
|
222
|
||||
|
12
|
39.0
|
238
|
2.2 V/VQ Series
2.2.1 Model Nomenclature
-
F3: Special fluid seal (omitted for standard petroleum-based fluids)
-
Series Designation: 20V/25V/35V/45V (industrial) / 20VQ/25VQ/35VQ/45VQ (mobile)
-
Displacement Code: Corresponding to displacement (see Table 2)
-
Pump Port Connection: A = SAE 4-bolt flange
-
Mounting Type: Omitted = flange mounting; F = foot mounting
-
Shaft Extension: 1 = straight shaft with key; 11 = spline shaft
-
Outlet Position: A/D = opposite inlet; B = 90° CCW; C = same side (viewed from cover end)
-
Rotation: L = counterclockwise; omitted = clockwise
2.2.2 Technical Specifications
|
Series
|
Displacement Code
|
Displacement (cm³/r)
|
Max Speed (rpm)
|
Max Pressure (MPa)
|
Weight (kg)
|
|---|---|---|---|---|---|
|
20V/20VQ
|
2-14
|
7.5-45
|
1800
|
14 (20V) / 21 (20VQ)
|
11.8
|
|
25V/25VQ
|
10-21
|
33-67
|
1800
|
17.5 (25V) / 21 (25VQ)
|
14.5
|
|
35V/35VQ
|
21-38
|
67-121
|
1800
|
17.5 (35V) / 21 (35VQ)
|
22.7
|
|
45V/45VQ
|
42-60
|
138-193
|
1800
|
17.5 (45V) / 21 (45VQ)
|
34
|
3. Double Vane Pumps
3.1 V2010/V2020 Series
3.1.1 Model Nomenclature
-
F3: Viton seals (omitted if not required)
-
Series Designation: V2010 (V20 shaft-end + V10 cover-end) / V2020 (V20 shaft-end + V20 cover-end)
-
Installation: 1 = 2-bolt flange
-
Inlet Connection: F = 4-bolt flange
-
Flow Code (Shaft-end Pump): Corresponding to V20 flow rate (6-13)
-
Outlet 1 Connection: S = 1.062-12 UN (V2010/V2020)
-
Flow Code (Cover-end Pump): V2010 (1-7, V10 flow); V2020 (6-13, V20 flow)
-
Outlet 2 Connection: S = 0.75-12 UN (V2010); 1.062-12 UN (V2020)
-
Shaft Type: 1 = straight key; 11 = spline
-
Outlet Positions: CC = Custom position (viewed from cover end)
3.1.2 Technical Specifications
|
Series
|
Shaft-end Pump Flow (USGPM)
|
Cover-end Pump Flow (USGPM)
|
Max Speed (rpm)
|
Max Pressure (MPa)
|
Feature
|
|---|---|---|---|---|---|
|
V2010
|
19.5-42.5
|
3.3-23.0
|
1800
|
14
|
Mixed flow rates for dual circuits
|
|
V2020
|
19.5-42.5
|
19.5-42.5
|
1800
|
14
|
Equal flow rates for high-volume demand
|
3.2 V Series Double Pumps
4. Core Features
-
Balanced Vane Design: Diametrically opposed inlet/outlet chambers balance radial loads, extending bearing life.
-
High Performance: Volumetric efficiency >90%, noise level as low as 62 dB(A), suitable for high-pressure operation.
-
Versatility: Compatible with petroleum-based oil and synthetic fire-resistant fluids; reversible rotation via internal part adjustment.
-
Compact Structure: Double pumps integrate two units in one housing, reducing installation space and simplifying drive system.
