YUKEN Hydraulic Pump PV2R2-60-F-RAA-41 Parameter Description
1. Model Code Interpretation
-
PV2R2: Series identifier, indicating a high-pressure, low-noise single fixed displacement vane pump of the PV2R2 series, designed for small to medium-displacement hydraulic system requirements, with compact structure, uniform output flow and stable performance for general working conditions.
-
60: Nominal displacement of the single pump unit, with a displacement of 60 cc/rev.
-
F: Mounting and port orientation code, specifying the pump’s installation type and oil port direction (specific details refer to YUKEN official technical manual).
-
RAA: Control and shaft end specification code, representing the pump’s control mode and shaft end structure configuration, consistent with YUKEN standard RAA series configuration.
-
41: Additional specification code, related to the pump’s seal type and other auxiliary configurations, adopting standard oil seal design to ensure good sealing performance.
2. Core Technical Parameters
|
Parameter Item
|
Specification
|
Unit
|
|
Pump Type
|
Single Fixed Displacement Vane Pump
|
–
|
|
Nominal Displacement
|
60
|
cc/rev
|
|
Maximum Operating Pressure
|
21.0 (210)
|
MPa (bar)
|
|
Maximum Rotational Speed
|
1800
|
rpm
|
|
Minimum Rotational Speed
|
750
|
rpm
|
|
Operating Temperature Range
|
0 – 60
|
℃
|
|
Shaft Seal Type
|
Standard Oil Seal (Refer to model 41 specification)
|
–
|
|
Mounting Type
|
Flange Mounting (JIS Standard)
|
–
|
|
Flange Bolt Specification
|
M16 (Strength Class 6.8), 4 pcs; Tightening Torque: 112 – 137 N·m
|
–
|
3. Performance Characteristics
-
Adopts a compact single vane pump structure, which saves installation space and ensures stable operation while meeting small to medium-flow hydraulic power demands; the output flow is more uniform than gear pumps, with low noise and long service life owing to balanced radial hydraulic force on the rotor shaft.
-
Features high efficiency, low noise, small pressure pulsation and high reliability, suitable for long-term continuous operation.
-
The installation and connection dimensions comply with national and international standards, facilitating replacement with domestic and foreign similar products.
-
The seals and cartridge kits are specially configured (model 41), adopting standard oil seal design to ensure good sealing performance and easy maintenance and replacement.
4. Application Scope
5. Notes
-
The pump should be used within the specified temperature and viscosity range to avoid performance degradation or damage caused by excessive temperature or inappropriate oil viscosity.
-
When installing, use the specified number and strength class of bolts, and tighten them according to the recommended torque to prevent bolt damage and hydraulic oil leakage.
-
For detailed dimensions, oil port specifications and maintenance methods, refer to YUKEN official technical manual (Document No. Pub.JM-0157).
