YUKEN hydraulic valve DSG-01, DSG-03 series

YUKEN hydraulic valve DSG-01 and DSG-03 series model guide

1. Model naming rules
   YUKEN’s DSG-01 and DSG-03 series hydraulic valve models follow the following general structure：
   DSG: Series logo (electromagnetic reversing valve)
   01/03: Diameter specifications (01 corresponds to 1/4 inch/6mm, 03 corresponds to 3/4 inch/10mm)
   Function code: such as 3C4 (three-digit four-way, center closed), 3C60 (three-digit four-way, center unloaded)
   Power supply type: D (DC) or A (AC), such as D24 (DC 24V), A220 (AC 220V)
   Additional features: N1 (with indicator light plug wiring), LA (enhanced protection), 70-L (high temperature resistant seal)
   Flow parameters: such as 50 (flow rate 50L/min)
   example：
   DSG-01-3C4-D24-N1-50: Three-position four-way, closed in the middle, DC 24V, with indicator light, flow rate 50L/min.
   DSG-03-3C60-A240-N1-50: three-position four-way, mid-position unloading, AC 240V, with indicator light, flow rate 50L/min.
2. Mainstream models and technical parameters
3. DSG-01 series
   Nominal pressure: 31.5MPa (some models support 35MPa)
   Flow range: ≤50L/min
   Typical model：
   DSG-01-3C4-D24-N1-50: Three-position four-way, closed middle position, DC 24V, flow rate 50L/min, suitable for machine tool hydraulic system.
   DSG-01-2B2-D24-LA: two-position four-way, spring return, DC 24V, enhanced protection, suitable for harsh environments such as metallurgy and mining.
   DSG-01-3C12-A110-N1-50: three-position four-way with pressure compensation, AC 110V, precision flow adjustment, suitable for test bench.
4. DSG-03 series
   Nominal pressure: 31.5MPa (some models support higher pressure)
   Flow range: ≥50L/min (such as 63L/min)
   Typical model：
   DSG-03-3C4-D24-N1-50: Three-position four-way, closed in the middle, DC 24V, flow rate 50L/min, suitable for injection molding machines.
   DSG-03-3C60-A220-N1-50: three-position four-way, mid-position unloading, AC 220V, large flow design, suitable for die-casting machines.
   DSG-03-2D2-A240-70-L: Two-position four-way, AC 240V, high temperature resistant sealing material, suitable for high temperature workshops.
5. Comparison of technical parameters
   Parameters DSG-01 DSG-03
   Nominal diameter 6mm (01 series) 10mm (03 series)
   Maximum pressure 35MPa 35MPa (some models support higher pressure)
   Flow range ≤50L/min ≥50L/min
   Action mode electromagnetic drive, wet valve core electromagnetic drive, wet valve core
   Typical applications machine tools, small hydraulic equipment, injection molding machines, die-casting machines, construction machinery

Fourth, the application scenario

1. DSG-01 series
   Typical application：
   Machine tool hydraulic system: high-precision control, such as DSG-01-3C4-D24-N1-50.
   Plastic machine: stable flow control, such as DSG-01-2B2-D24-LA.
   Hydraulic truck: compact design, adapt to space constraints.
   Advantages: high precision, high reliability, long life, easy maintenance.
2. DSG-03 series
   Typical application：
   Injection molding machine: large flow requirements, such as DSG-03-3C60-A220-N1-50.
   Die-casting machine: high-pressure working conditions, such as DSG-03-3C4-D24-N1-50.
   Construction machinery: adaptability to harsh environments, such as DSG-03-2D2-A240-70-L.
   Advantages: high voltage and large flow, low pressure loss, micro-current control.
